High Voltage Disconnecting Switch
Product Title
Product Details
GN27-40.5/630A indoor high voltage disconnecting switch is a three-phase AC 50Hz high voltage switchgear, used for making and breaking circuits under voltage and no-load conditions in 35kV power systems. Equipped with CS6-2 manual operating mechanism or CX6 electric mechanism.
GN27-40.5/630A indoor high voltage disconnecting switch is a three-phase AC 50Hz high voltage switchgear, used for making and breaking circuits under voltage and no-load conditions in 35kV power systems. Equipped with CS6-2 manual operating mechanism or CX6 electric mechanism.
| Model | Rated Voltage (kV) | Rated Current (A) | Rated Short-time Withstand Current RMS/Time (kA/4s) | Rated Peak Withstand Current (kA) | Lightning Impulse Withstand Voltage (kV) | 1min Power Frequency Withstand Voltage (kV) | ||
| To Earth and Between Poles | Across Gap | To Earth and Between Poles | Across Gap | |||||
| GN27-41.5CD/630-20 | 40.5 | 630 | 20/4S | 50 | 185 | 215 | 95 | 115 |
| GN27-41.5CD/1250-31.5 | 40.5 | 1250 | 31.5/4S | 80 | 185 | 215 | 95 | 115 |
Please strictly follow the GN27-40.5/630A Indoor High Voltage Disconnecting Switch product specifications for installation and operation to ensure the safe and stable operation of the power system and distribution equipment.
GN27-40.5 indoor disconnecting switch is suitable for 40.5kV switchgear. Installation requires blade insertion depth into fixed contact ≥20mm, phase-to-phase insulation partition without deformation or arc burn marks, transmission linkage pin shafts regularly lubricated with molybdenum disulfide grease, five-prevention interlock device verified item by item before operation.GN27-40.5 Indoor High Voltage Disconnecting Switch GN27-40.5/630A
